HKL-4402 Rotational Viscometer for Asphalt Viscosity
Overview
HKL-4402 Rotational Viscometer for Asphalt Viscosity conforms to ASTM D4402 Standard Test Method for Viscosity Determination of Asphalt at Elevated Temperatures Using a Rotational Viscometer. This test method outlines a procedure for measuring the apparent viscosity of asphalt from 38 to 260°C [100 to 500°F] using a rotational viscometer and a temperature-controlled thermal chamber for maintaining the test temperature.
Features
1. Utilizes ARM technology with a built-in Linux system. The operation interface is simple and clear, enabling quick and convenient viscosity testing through the creation of test programs and data analysis.
2. Accurate viscosity measurement: Each range is automatically calibrated by computer, ensuring high precision and minimal error.
3. Comprehensive display content: In addition to viscosity (dynamic viscosity and kinematic viscosity), it also shows temperature, shear rate, shear stress, percentage of full-scale measurement value (graphical display), range overflow alarm, automatic scanning, maximum measurement range under the current rotor speed combination, date, time, etc. Kinematic viscosity can be displayed when density is known, meeting users' diverse measurement requirements.
4. Complete functionality: Supports timed measurement, creation of 30 custom test programs, storage of 30 measurement data sets, real-time viscosity curve display, printing of data and curves, etc.
5. Front-mounted level: Intuitive and convenient level adjustment.
6. Stepless speed adjustment:
7. RV1T series: 0.3-100 rpm, 998 speed options in total
8. RV2T series: 0.1-200 rpm, 2000 speed options in total
9. Display of shear rate vs. viscosity curve: The shear rate range can be set and displayed in real-time on the computer; time vs. viscosity curve can also be displayed.
10. Optional Pt100 temperature probe: Wide measurement range from -20 to 300°C, with temperature accuracy of 0.1°C.
11. The measurable range is extremely wide, from 50 to 80 million mPa·s, capable of handling various high-viscosity, high-temperature molten samples (such as hot-melt adhesives, asphalt, plastics, etc.).
12. When equipped with an ultra-low viscosity adapter (Rotor 0), it can also measure the viscosity of molten samples like paraffin wax and polyethylene wax.
13. Widely applied in medium to high viscosity industries including paints, coatings, cosmetics, inks, pulp, food, oil products, starch, solvent-based adhesives, latex, biochemical products, etc.
Technical Parameters
Model | HKL-RVDV-1T-H | HKL-HADV-1T-H | HKL-HBDV-1T-H |
Control / display mode | 5-inch color touch screen | ||
Speed（r/min） | 0.3–100 Continuously variable speed, a total of 998 speed options | ||
Measuring range
| 6.4 - 3.3M Rotor NO.0: 6.4 - 1K Rotor NO.21: 50-100K Rotor NO.27: 250-500K Rotor NO.28: 500-1M Rotor NO.29: 1K-2M | 12.8 - 6.6M Rotor NO.21: 100-200K Rotor NO.27: 500-1M Rotor NO.28: 1K-2M Rotor NO.29: 2K-4M | 51.2 - 26.6M Rotor NO.21: 400-1.3M Rotor NO.27: 2K-6.7M Rotor NO.28: 4K-13.3M Rotor NO.29: 8K-26.6M |
K = 1000; M = 1000000 | |||
Rotor | 21#, 27#, 28#, 29# (4 pieces, standard), 0# (optional) | ||
Sample consumption | Rotor 0#: 21ml Rotor 21#: 7.8ml Rotor 27#: 11.3ml Rotor 28#: 12.6ml Rotor 29#: 11.5ml | ||
Measurement error | ±1% | ||
Repeatability error | ±0.5% | ||
Show shear response / shear rate | standard configuration | ||
Timing function | standard configuration | ||
Real-time display Viscosity curve | Time-viscosity curve Temperature-viscosity curve (optional temperature probe) (Optional data processing software shows shear rate and viscosity curves) | ||
Kinematic viscosity | Density of samples to be entered | ||
Temperature measurement function | Standard temperature probe interface (optional temperature probe) | ||
Automatic Scanning Function | Automatically scan and recommend the preferred combination of rotor and rotation speed | ||
Maximum measurement range | Automatic display of selected combinations of rotor and rotation speed. Measurable viscosity range | ||
Self-built Measuring Procedures | Up to 30 groups (including rotor, speed, temperature, time, etc.) | ||
Preservation of measurements | Up to 30 sets of data (including viscosity, temperature, rotor, speed, shear rate, shear stress, time, density, kinematic viscosity, etc.) | ||
Data, curve can be printed (standard print interface, need to buy printer) | |||
Data output interface | RS232 | ||
Thermostatic components | Selections (including various viscometer special thermostatic tank, thermostatic cup, temperature control device, heating furnace) | ||
Working power supply | Wide voltage operation (110 V/60 Hz or 220 V/50 Hz) | ||
Outline dimension | 300 × 300 × 450（mm） | ||
Model | HKL-RVDV-2T-H | HKL-HADV-2T-H | HKL-HBDV-2T-H |
Control / display mode | 5-inch color touch screen | ||
Speed（r/min） | 0.3–100 Continuously variable speed, a total of 998 speed options | ||
Measuring range
| 3.2 - 10M Rotor NO.0: 3.2 - 1K Rotor NO.21: 50-500K Rotor NO.27: 125-2.5M Rotor NO.28: 250-5M Rotor NO.29: 500-10M | 6.4 - 20M Rotor NO.21: 150-1M Rotor NO.27: 250-5M Rotor NO.28: 500-10M Rotor NO.29: 1K-10M | 25.6 - 80M Rotor NO.21: 200-4M Rotor NO.27: 1K-20M Rotor NO.28: 2K-40M Rotor NO.29: 4K-80M |
K = 1000; M = 1000000 | |||
Rotor | 21#, 27#, 28#, 29# (4 pieces, standard), 0# (optional) | ||
Sample consumption | Rotor 0#: 21ml Rotor 21#: 7.8ml Rotor 27#: 11.3ml Rotor 28#: 12.6ml Rotor 29#: 11.5ml | ||
Measurement error | ±1% | ||
Repeatability error | ±0.5% | ||
Show shear response / shear rate | standard configuration | ||
Timing function | standard configuration | ||
Real-time display Viscosity curve | Time-viscosity curve Temperature-viscosity curve (optional temperature probe) (Optional data processing software shows shear rate and viscosity curves) | ||
Kinematic viscosity | Density of samples to be entered | ||
Temperature measurement function | Standard temperature probe interface (optional temperature probe) | ||
Automatic Scanning Function | Automatically scan and recommend the preferred combination of rotor and rotation speed | ||
Maximum measurement range | Automatic display of selected combinations of rotor and rotation speed. Measurable viscosity range | ||
Self-built Measuring Procedures | Up to 30 groups (including rotor, speed, temperature, time, etc.) | ||
Preservation of measurements | Up to 30 sets of data (including viscosity, temperature, rotor, speed, shear rate, shear stress, time, density, kinematic viscosity, etc.) | ||
Data, curve can be printed (standard print interface, need to buy printer) | |||
Data output interface | RS232 | ||
Thermostatic components | Selections (including various viscometer special thermostatic tank, thermostatic cup, temperature control device, heating furnace) | ||
Working power supply | Wide voltage operation (110 V/60 Hz or 220 V/50 Hz) | ||
Outline dimension | 300 × 300 × 450（mm） | ||
