HKL-TD5A Tabletop Low-Speed Centrifugation System
Overview
Low-speed Centrifuge Series features high efficiency specimen separation with fluency and speed. These are quite suitable for medical, biological and research labs. This is the perfect equipment for a hospital and a blood bank since serum, plasma, urine and RIA samples are carried out on a regular basis.
Features
This system is a very accurate micro-computer control system with frequency changing motor drive. It also has a 5-inch touch screen which indicates the speed, the working time, and the setting of acceleration/deceleration simultaneously. Besides, it can keep track of the working log and fault history in real time and it has an outside USB port for instant data export to support data integrity.
This software makes it possible to design your own multi-step running protocols while automatically converting RCF. You are free to change settings anytime, even save them so that you can adjust the centrifugation exactly to the requirements of your application.
This centrifuge has an all-steel frame and special damping materials which not only enhance the stability of its operation but also contribute to reducing the noise level.
The electronic door lock is linked with a gas-spring-assisted lid support and features integrated protection against overspeed, overload and door closure faults, as well as control of the door closure process by the frequency sweeper.
This equipment is capable of working with various types of rotors, allowing it to fulfill the diverse needs of testing across different application areas.
The system is equipped with a manual program lock feature and automatic rotor identification, as well as ventilation ducts built-in to the body of the machine which effectively prevent the temperature inside the centrifuge chamber from rising too high.
Technical Parameters
Max Speed: 6000 r/min
Noise Level: ≤ 60 dB
Maximum Capacity: 4×300 ml
Centrifuge Chamber Diameter: φ400 mm
Maximum Relative Centrifugal Force (RCF): 4750 ×g
Power Supply: AC 220 V / 50 Hz / 0.75 kW
Timer Range: 1min~99h59min
Speed Accuracy: ±20 r/min
Net Weight: 55 kg
Dimensions (L×W×H): 620 × 460 ×360 mm
Compatible Rotor
Rotor ID | Rotor Type | Capacity (ml) | Max Speed (r/min) | Max RCF (×g) |
NO0701 | swing-bucket rotor | 4x50ml | 5000r/min | 4750xg |
NO0702 | swing-bucket rotor | 4x100ml | 5000r/min | 4750xg |
NO0703 | swing-bucket rotor | 4x2x50ml | 4000r/min | 3280xg |
NO0720 | swing-bucket rotor | 4x8x15ml | 4000r/min | 3280xg |
NO0704 | swing-bucket rotor | 4x2x100ml | 4000r/min | 3050xg |
NO0706-1 | swing-bucket rotor | 4x24x7/5ml Blood Collection Tube | 4000r/min | 2950xg |
NO0707 | swing-bucket rotor | 4x300ml（250ml Centrifuge Bottles） | 4000r/min | 3100xg |
NO0707-4 | swing-bucket rotor | 4x18x7/5ml Automatic- decapping | 4000r/min | 2980xg |
NO0722 | swing-bucket rotor | 2x3x96-well Microplate | 4000r/min | 2350xg |
NO0776 | Fixed-angle rotor | 6x50ml | 6000r/min | 4150xg |
NO0777 | Fixed-angle rotor | 8x50ml | 6000r/min | 4550xg |
NO0778 | Fixed-angle rotor | 6x100ml | 6000r/min | 4550xg |
NO0779 | Fixed-angle rotor | 12x15ml | 6000r/min | 4450xg |
NO0780 | Fixed-angle rotor | 24x15ml | 4000r/min | 3550xg |
PRP | swing-bucket rotor | 4x50ml Syringe | 4000r/min | 3200xg |
CGF1-4 | swing-bucket rotor | 4x50ml Syringe | 4-step fixed gradient program | |
11-14 | swing-bucket rotor | 4-step adjustable gradient program | ||
Centrifuge Rotor
FAQ
Q1: What are the primary applications and features of HKL-TD5A Tabletop Low-Speed Centrifugation System？
A: The Low-speed Centrifuge series offers a perfect way to separate samples in clinical, biological, and research labs. The stable and dependable low-speed centrifuge products are gradually becoming the essential parts of the packaging of serum, plasma, urine, and RIA in hospitals and blood banks.
Q2: Are the technical parameters listed on the product page the definitive figures? Is there a more comprehensive technical specification sheet that can be provided?
A: The parameters listed on the page are simple general specifications only. Due to changes in the configuration and model, the exact performance figures of individual units will vary. Thus, please send us a message and we will give you the latest and the most detailed official specification sheet of that particular model.
Q3: What kinds of instruments does your company mainly provide?
A: Hi! We have experienced staff in analyzing life science, monitoring environment, and controlling automation in industries. Our main offerings are gas chromatographs, viscometers, spectrometers, centrifuges, etc. For the detailed list of products and technical specifications, please visit the Product Center on our official website.
Q4: I don’t know which product is right for my testing/production needs. Can you help me decide?
A: Absolutely! Our engineering staff is expertly trained and ready to assist you in selecting the appropriate model by discussing your individual needs (e.g. sample type, detection level and budget). Simply click the Online Consultation button on the right-hand side of the page or fill out the Request Form and we will respond to you soon.
Q5: Which international shipping options are available in your store?
A: We have several international shipping options that you can choose from, depending on the volume of your order: International Express (DHL, FedEx, UPS, TNT) mainly for small and valuable items; Air Freight for medium volume; Sea Freight (FCL/LCL) for bulk orders (transit time 20–40 days); and Rail Freight by the China-Europe Railway Express for customers located across Eurasia.
