Detection Target
Determination of Polychlorinated Biphenyls (PCBs) in Waste Materials
Overview
This solution conforms to ASTM D6160 Standard Test Method for Determination of Polychlorinated Biphenyls (PCBs) in Waste Materials by Gas Chromatography. This test method Provides sufficient PCB data for many regulatory requirements. While the most common regulatory level is 50ppm (dry weight corrected), lower limits are used in some locations. Since sensitivities will vary for different types of samples, one shall demonstrate a sufficient method detection limit for the matrix of interest. This test method differs from Test Method D4059 in that it provides for more sample clean-up options, utilizes a capillary column for better pattern recognition and interference discrimination, and includes both a qualitative screening and a quantitative results option.
Apparatus
HKL-6160 GC for Determination of PCBs
Chromatogram
Configuration
|
NO. |
Name |
Specification |
Qty. |
|
1 |
HKL-6160 GC for Determination of PCBs |
1.Big LCD display, boot self-checking, wide range diagnosis function, intelligent fuzzy control system, opening after power; over temperature protection function, six-stage rise 2.Configuration: main host + capillary tube injection port (split/splitless) |
1 set |
|
2 |
ECD + Amplifier board |
Adopts Ni63370MBq radiation source, working temperature can reach 350℃, Suitable for the analysis of halides such as pesticide residues Analysis: Pesticide Residues Organochlorine |
1 set |
|
3 |
Work station |
Dedicated for double channels |
1 set |
|
4 |
Capillary Column |
For PCBs |
1pc |
|
5 |
PC + Printer |
Self-prepared |
1 set |
|
6 |
Nitrogen cylinder |
Purity: 99.999 Cylinder + reducing valve Self-prepared |
1 set |
