HKL-4007 Crude Oil Water Content Testing Centrifuge
Overview
HKL-4007 Crude Oil Water Content Testing Centrifuge conforms to the ASTM D4007 standard test method for Water and Sediment in Crude Oil by the Centrifuge Method and ASTM D893 standard Test Method for Insolubles in Used Lubricating Oils. Equal volumes of crude oil and water-saturated toluene are placed into a cone-shaped centrifuge tube. After centrifugation, the volume of the higher density water and sediment layer at the bottom of the tube is read.
Features
The centrifuge is equipped with a microcomputer processor for accurate control. Its large 7-inch high-definition LCD touchscreen can display various information at the same time such as rotor number, speed, time, temperature, centrifugal force, acceleration/deceleration rate, and fault details.
With an annular heating element for automatic temperature control, it can heat up quickly and distribute temperature evenly.
The glass tubes are made through a unique process; that is why they can still remain intact after the operation.
Sensor based electric door lock automatically operated and it can be unlocked in emergency, drastically reduces operator workload.
Built-in overspeed, overtemperature, and imbalance protection systems. The stainless-steel chamber is equipped with three layers of protection, making it safe, reliable, and easy to use. Run data export via a USB interface is provided, which ensures the integrity of data.
The direct-axis motor spindle offers better thermal stability. The alloy aluminum rotor base is lined with heat-resistant silicone pads, effectively protecting glass tubes during centrifugation.
Technical Parameters
Max Speed: 5000 r/min
Noise Level: ≤58 dB
Max Capacity: 4 × 800 ml
Power Supply: AC 220V, 50Hz, 1.5 kW
Max Relative Centrifugal Force (RCF): 4750 ×g
Temperature Range: Ambient +10°C ~ 100°C
Timer Range: 1s ~ 99h 59min 59s
Speed Accuracy: ±20 r/min
Net Weight: 67 kg
Dimensions (L×W×H): 680 × 502 × 392 mm
Compatible Rotors
Rotor ID | Rotor Type | Capacity(ml) | Max Speed(r/min) | Max RCF(×g) |
NO2901 | Swinging-bucket rotor | 4x50ml | 5000r/min | 4750xg |
NO2902 | Swinging-bucket rotor | 4x100ml | 5000r/min | 4750xg |
NO2903 | Swinging-bucket rotor | 4x2x50ml | 4000r/min | 3280xg |
NO2920 | Swinging-bucket rotor | 4x8x15ml | 4000r/min | 3280xg |
NO2904 | Swinging-bucket rotor | 4x2x100ml | 4000r/min | 3050xg |
NO2905 | Swinging-bucket rotor | 4x100ml--BL | 2500r/min | 1500xg |
NO2908 | Swinging-bucket rotor | 4x800ml | 4000r/min | 3530xg |
Centrifuge Rotor
FAQ
Q1: What standards does this product (HKL-4007 Crude Oil Water Content Testing Centrifuge) comply with?
A: HKL-4007 Crude Oil Water Content Testing Centrifuge conforms to the ASTM D4007 standard test method for Water and Sediment in Crude Oil by the Centrifuge Method and ASTM D893 standard Test Method for Insolubles in Used Lubricating Oils. This test method describes the laboratory determination of water and sediment in crude oils by means of the centrifuge procedure. This test method may not be suitable for crude oils that contain alcohols that are soluble in water.
Q2: Significance and use of HKL-4007 Crude Oil Water Content Testing Centrifuge?
A: The water and sediment content of crude oil is significant because it can cause corrosion of equipment and problems in processing. A determination of water and sediment content is required to measure accurately net volumes of actual oil in sales, taxation, exchanges, and custody transfers.
Q3: What is the minimum order quantity? How long is the delivery lead time?
A: The minimum order quantity is one unit, and delivery is approximately 20 days after advance payment.
Q4: Do you provide product operation manuals or technical documentation?
A: Yes, we offer electronic versions of product manuals, quick operation guides, application cases, and standard operating procedures (SOPs). These can be accessed by logging into the download center on our official website or by contacting customer service to request them.
Q5: How do I track my order?
A: After the package leaves the warehouse, we'll send you the tracking number / bill of lading number and the tracking link. Through the courier's or logistics company's official website, you can follow your shipment in real-time or simply get in touch with our customer service.
