HKL-GL10 Floor-standing High-speed Refrigerated Centrifuge
Overview
Designed especially for the needs of today’s bioscience, this floor-standing high-speed refrigerated centrifuge series is ideally suited for tasks like the separation of blood, harvesting of cells, and precipitation of proteins. This powerful and dependable piece of equipment is a great addition to the labs of biochemical research, bioprocessing, and vaccine manufacturing as it can produce the same great results even with the most challenging applications.
Features
Driven by a microcomputer-based precision control and a variable frequency motor drive, this system features a 7-inch touchscreen that displays the speed, temperature, run time, and acceleration/deceleration in real-time. Operation records and fault logs can be checked easily, and there is a USB port outside that allows immediate data export so that the data will be kept intact.
Equipped with user-friendly programming, this system offers multiple stages operation and automated RCF calculations. Users can easily customize, save, and adjust the protocols for different application requirements.
Built with a sturdy all-steel frame and a blast-proof inner cavity, the centrifuge is equipped with a sophisticated multi-layer damping system that guarantees excellent stability during operation and low noise levels.
The machine features a state-of-the-art and environment-friendly fluorine-free compressor that provides excellent cooling performance: 4°C in 5 minutes. As a result, it greatly improves experimental throughput and efficiency through the workflow.
Reliable operation is guaranteed by a well-rounded safety system. Among these components is a door lock that is sensor-controlled (comes with an emergency release), in addition to the protective features that automatically defend against overspeed, overload, and wrong lid closure.
The equipment, being very flexible, offers the options to work with various types of rotors in different sizes which made it possible for the unit to meet the diverse requirements of the scientific community for their different types of works.
The system additionally features a manual program lock and the automation of rotor identification.
Technical Parameters
Maximum Speed: 10000 r/min
Noise Level: ≤ 65 dB
Maximum Capacity: 6 × 1000 ml
Centrifuge Chamber Diameter: Φ700 mm
Maximum Relative Centrifugal Force (RCF): 18500 ×g
Power Supply: AC 380 V / 50 Hz / 8 kW
Timer Range: 1 min ~ 99 h 59 min
Speed Accuracy: ±10 r/min
Temperature Control Range: −20°C ~ +40°C
Temperature Control Accuracy: ±1°C
Net Weight: 580 kg
Dimensions (L × W × H): 960× 900 × 988mm
Compatible Rotor
Rotor ID | Rotor Type | Capacity (ml) | Max Speed (r/min) | Max RCF (×g) |
NO3764 | Fixed-angle rotor | 6 × 300 ml | 10000 r/min | 15800 ×g |
NO3765 | Fixed-angle rotor | 6 ×500 ml | 10000 r/min | 18500 ×g |
NO3766 | Fixed-angle rotor | 4 × 1000 ml | 9000 r/min | 16200 ×g |
NO3767 | Fixed-angle rotor | 6 × 1000 ml | 8000 r/min | 15200 ×g |
Contrifuge Rotor
