HKL-TGL16E Benchtop High-speed Refrigerated Centrifuge
Overview
Different workflows in modern life sciences can be supported using this High-speed Refrigerated Centrifuge series. The series used in molecular diagnostics, nucleic acid purification, cell fractionation, and microbial analysis. For medical research, biotechnology, agricultural and environmental testing, as well as university and institutional laboratories, this High-speed Refrigerated Centrifuge series is a great fit.
Features
Integrating the accurate microcomputer control with an inverter motor drive, this unit features a 7-inch touchscreen allowing real-time display of speed, temperature, runtime, and acceleration/deceleration settings all at once. It makes it possible to keep track of operational logs as well as error records, and contains an external USB port for instantly exporting data thus preserving data integrity.
Equipped with a stepwise programmable control feature and automatic RCF determination, this device offers complete flexibility from start to finish in making, saving, and personalizing user’s protocols.
With a steel monocoque chassis and containment-rated inner chamber, this centrifuge ensures great operational stability. Besides, it has a complex multi-layer damping system that reduces noise levels extraordinarily.
Eco-friendly and fluorine-free compressors are the source of this rapid cooling capability. The cooling temperature reaches 4℃ within just five minutes, which in turn enhances the effectiveness of the tests.
The safety features are a sensor-based electric door lock that has emergency release capability, as well as built-in protection against overspeed, overload, and lid-open situations.
The system has been designed for versatility and is compatible with a wide range of rotors of different capacities that can meet diverse testing requirements for multiple disciplines.
Other functions that may come into play are manual program locking and automatic rotor recognition.
Technical Parameters
Max Speed: 16500 r/min
Noise Level: ≤ 60 dB
Maximum Capacity: 6×10 ml
Centrifuge Chamber Diameter: φ220 mm
Maximum Relative Centrifugal Force (RCF): 19150 ×g
Power Supply: AC 220 V / 50 Hz / 1.5kW
Timer Range: 1min~99h59min
Speed Accuracy: ±10 r/min
Temperature Control Range: -20°C~+40°C
Temperature Control Accuracy: ±1°C
Net Weight:68kg
Dimensions (L×W×H): 630× 330×290 mm
Compatible Rotor
Rotor ID | Rotor Type | Capacity (ml) | Max Speed (r/min) | Max RCF (×g) |
NO3901 | Fixed-angle rotor | 12x1.5/2ml | 16500r/min | 18700xg |
NO3902 | Fixed-angle rotor | 24x1.5/2ml | 14000r/min | 18050xg |
NO3903 | Fixed-angle rotor | 30x1.5/2ml | 13000r/min | 17980xg |
NO3904 | Fixed-angle rotor | 48x1.5/2ml | 12000r/min | 15300xg |
NO3905 | Fixed-angle rotor | 4x8 PCR | 14000r/min | 12100xg |
NO3906 | Fixed-angle rotor | 10x5ml | 16000r/min | 17900xg |
NO3907 | Fixed-angle rotor | 6x10ml | 13000r/min | 14260xg |
NO3908 | Fixed-angle rotor | 40x0.2ml | 16000r/min | 19150xg |
Centrifuge Rotor
FAQ
Q1: What is the main application fields of HKL-TGL16E Benchtop High-speed Refrigerated Centrifuge?
A: The range of High-speed Refrigerated Centrifuge is capable of operating in different workflows in life sciences of the present, for instance molecular diagnostics, nucleic acid purification, cell fractionation, and microbial analysis. Besides, it can be efficiently used in medical research, biotechnology, agricultural and environmental testing, and also in the university and institutional laboratories.
Q2: Would you be able to share a sample with us?
A: Trial samples are available on request (sample and delivery charges may apply) for low-value consumables and accessories. However, as capital equipment requires a significant investment, we recommend either looking at our customer success stories or arranging to have a demonstration at the site.
Q3: Do you offer online training services?
A: If you need assistance, we are ready to support you through online installation and commissioning services, detailed operational training. Also, we offer all year, 24/7 online training support for the end-users.
Q4: How do I keep an eye on my shipment?
A:Once your shipment is dispatched from our warehouse, the tracking details will be shared with you. It will allow you to monitor the progress of your shipment at any time through the carrier's website or by contacting us.
Q5: Could you please provide a more detailed technical specification sheet?
A: The parameters on the page refer to very basic/general specifications and due to configuration and model differences, the exact performance data of each unit can vary. Please contact us directly and we shall provide you with the most up-to-date and detailed official specification sheet for that particular model.
About us
Hong Kong Laboratory Technology Limited was founded in 2018 and has since become a trusted partner in the instrument supply chain. With over eight years of industry experience, we have built strong connections within the industry and are known as a reliable source. We are working with 50+ internationally recognized brands, and through them, we provide service to over 500 clients by converting advanced technologies into practical, everyday solutions. Our main principles are based on the most widely accepted international standards such as ISO 9001, ASTM, and IP, and we strictly adhere to ISO/IEC 17025 calibration standards for our key instruments. We serve a large variety of sectors—from scientific research organizations to industrial petrochemical plants—providing comprehensive support that covers detailed needs analysis, expert technology consulting, and reliable post-sales service. Choosing us will make your equipment purchasing experience smooth, accurate, and completely worry-free.
Company Advantages
(1)Capability of integration full-chain resource
(2)Professional Technical Team
(3)Rich Industry Practical Cases
(4)Reliable After-Sales Service
Service Guarantee
1. Online Training Services
We have online support system in place that covers from start to end of your operation life. We offer remote-guided installation and commissioning. Besides, we prepare training programs as thoroughly as possible. To ensure you can maintain your business at its best level, our technical support team would be always available to assist you, consult, and give you advanced teaching sessions 24/7.
2. Professional After-Sales Service
Our custom maintenance services are meant to maintain the highest performance of your equipment. We strive to be the leaders in reliability and accuracy. Besides, your opinions matter a lot to us; they allow us to get your service experience better and better with time.
Logistics and Shipping
Worldwide Shipping: We combine the best operational skills with profound regional knowledge to guarantee the most accurate and careful handling of your cargo throughout Asia, Europe, and the Middle East. Our pledge is straightforward: efficient and dependable delivery, always.
Secure Packaging: Lab instruments are packed according to strict packaging standards, which provide a very tight packaging wrapping protecting the instruments from the shocks and vibrations during transport/hyperspace transfer.
International Certification
|
|
ISO 9001 Certification | ASTM Certificate |
