HKL-1748 Humidity Cabinet for Rust Protection
Overview
The HKL-1748 Humidity Cabinet for Rust Protection conforms to ASTM D1748 Standard Test Method for Rust Protection by Metal Preservatives in the Humidity Cabinet. After steel panels are finished to a specific standard, they are dipped into the test oil. When the oil is drained, the panels are hung in a humidity cabinet at 48.9°C (120°F) for a certain number of hours. The oil is considered to have failed or passed the test depending on the size and the number of rust dots found on the test surfaces of the panels.
Features
This instrument is equipped with a microcomputer controlled digital temperature regulator that allows for very accurate temperature control, programmable heating with easy operation and dependable precision.
The operating temperature may be accurately controlled, and the chamber’s digital display is very clear for reading the temperature without errors.
Equipped with a special leakage protection device that automatically cuts off power, ensuring the safety of both operators and test samples.
A dedicated flow control system guarantees that air circulation in the chamber meets professional testing requirements.
The compact design and very efficient use of chamber space make this unit especially suited for researchers who carry out independent studies.
This product is a benchtop testing instrument that simulates humid environments. It is suitable for industries such as petroleum, chemical, and machinery, as well as universities and research institutions, to test and evaluate the rust-preventive properties of lubricants on metals.
Structures
This product consists primarily of a chamber body, a door, a temperature and humidity control system, a ventilation system, and an electrical control system. The external casing is a high-quality cold-rolled steel plate with a plastic-coated surface coloring; the inside lining is of stainless steel. The slopping top of the interior lining can effectively stop the condensation droplets from falling onto the test samples. The door contains a viewing window so that the tester can check the running of the test. The turntable speed is 1/3 r/min at a steady rate. Starting or stopping the turntable is as simple as flipping a switch on the control panel. Hanging slots on the turntables makes it possible to fasten the test specimens. In fact, the turntable, oil drip tray, and tray bracket can all be taken out for maintenance quite easily. The light switch comes handy when the operator wants to check the test samples. This switch should be turned off when the light is no longer needed. An air flow meter controls the air flow. Opening the valve in the flow meter allows one to set the air flow rate to the desired value.
The electrical control compartment is located beneath the chamber.
This product is integrated with a temperature alarm system that triggers in case of overheating and a heating cutoff protection system. The heat source mainly comprises a heater installed at the bottom of the chamber, and its operation is managed by a dry-bulb temperature controller. Out of two control instruments, one is responsible for controlling the dry-bulb temperature of the working chamber, and the other one cooperates with the dry-bulb thermometer to indicate the wet-bulb temperature. If the chamber (dry-bulb) temperature falls below the set value, the dry-bulb controller will provide a heating signal which will turn on the heaters to raise the temperature. If the chamber temperature goes above the set value, the dry-bulb controller will not output any signal which consequently switches off the heaters and the temperature will start to fall. After repeating several cycles, the temperature finds its balance and gets to the equilibrium level, thereby satisfying the control requirements. Generally, the dry-bulb temperature is kept under program control so that the amount of overshooting is kept to a minimum and the quality of temperature regulation is hardly any less than perfect.
The external compressed air supply must be provided by the user, and the air source must be clean.
Technical Parameters
Applicable Standards: ASTM D1748
Operating Temperature: 49 ± 1°C
Temperature Fluctuation: ≤ ±0.5°C
Relative Humidity in Chamber: 95% RH
Sample Rack Rotation Speed: 1/3 r/min ± 10%
Airflow Rate: 0.4 m³/h (adjustable within 0.1~1 m³/h range)
Heating and Stabilization Time: ≤180 min
Water Tank Depth: 210 mm
Power Supply: 220 ± 22 V, 50 ± 0.5 Hz, 2.3 KW
Chamber Dimensions: 490 × 500 × 520 mm (Effective chamber volume: 137 L)
Overall Dimensions: 790 × 640 × 1293 mm
Packing Dimensions: 955 × 840 × 1440 mm
Gross Weight: 150 kg
Operating Environmental Conditions
Ambient Temperature Range: 15°C to 35°C
Relative Humidity: ≤85% R.H.
Power Supply: AC 220V ±22V, 50Hz ±1Hz
The surrounding area is free from strong vibrations and other cold or heat sources that could affect the product.
The environment is well-ventilated, with clean surrounding space, and free from flammable, explosive, or corrosive gases.
Pre-installed compressed air source: pressure 0.2×10⁵ Pa～0.6×10⁵ Pa; flow rate ≥0.08 m³/min.
FAQ
Q1: What standards does this product (HKL-1748 Humidity Cabinet for Rust Protection) comply with? What is the applicable scope of the instrument?
A: The HKL-1748 Humidity Cabinet for Rust Protection conforms to ASTM D1748 Standard Test Method for Rust Protection by Metal Preservatives in the Humidity Cabinet. Steel panels are prepared to a prescribed surface finish, dipped in the test oil, allowed to drain, and then suspended in a humidity cabinet at 48.9°C (120℉) for a specified number of hours. The oil fails or passes the test in accordance with the size and number of rust dots on the test surfaces of the panels. This test method is used for evaluating the rust-preventive properties of metal preservatives under conditions of high humidity.
Q2: Significance and use of HKL-1748 Humidity Cabinet for Rust Protection?
A: This test method is used for measuring the relative abilities of metal preservatives to prevent the rusting of steel panels under conditions of high humidity. It should not be relied upon to predict the effectiveness of a metal preservative in which high humidity is not the principal factor in the rusting. Comparisons made by this test method should normally be limited to similar metal preservative combinations designed for similar applications. The test life required for each type of metal preservative and for each intended application should be based on actual experience with that type of preservative in the intended service.
Q3: What is the minimum order quantity? How long is the delivery lead time?
A: The minimum order quantity is one unit, and delivery is approximately 20 days after advance payment.
Q4: How can I get a product quotation?
A: Please submit your requirements via the contact page on our official website or customer service email, and we will contact you within 24 hours with a detailed quotation.
Q5: Do you offer customized solutions?
A: Yes, we can provide customized instrument configurations and testing solutions based on the customer’s specific application need
