HKL-665 Rust-preventing Characteristics Tester
Overview
HKL-665 Rust-preventing Characteristics Tester conforms to the ASTM D665 Standard Test Method for Rust-Preventing Characteristics of Inhibited Mineral Oil in the Presence of Water. This apparatus covers the evaluation of the ability of inhibited mineral oils, particularly steam-turbine oils, to aid in preventing the rusting of ferrous parts should water become mixed with the oil. This test method is also used for testing other oils, such as hydraulic oils and circulating oils. Provision is made in the procedure fortesting heavier-than-water fluids.
Features
The instrument is fitted with an electric heat tube that produces heat and the temperature is sensed by a Pt100 sensor. This sensor is capable of providing superior thermal response, high measurement resolution, strong noise immunity, small size, and precise temperature control and reading, the readings being displayed digitally.
The instrument panel features a touch-sensitive panel that enables users to control it with a mere light touch.
To remove temperature stratification, an automatic stirring system is included that ensures even temperature throughout the bath with less manual work.
Featuring a simple interface for watching live changes to sample temperature and very precise adjustment capabilities, this digital controller will allow you to control sample temperature accurately and efficiently.
With a four-place head, this instrument is capable of preparing four samples at the same time. It is built for continuous, non-stop working with superior temperature stability.
The highly precise timer ensures accurate and reliable time measurement.
The instrument is fitted with state-of-the-art Grinding and Polishing Equipment that not only meets the standards but also ensures top-notch performance.
Technical Parameters
Model: HKL-665
Heating Method: Electric heating tube
Temperature Control Method: Imported digital PID temperature controller
Switch Control: Touch panel operation
Heating Temperature: Ambient temperature ~ 90°C ±1°C
Working Units: 4 independent stirring stations
Stirring Method: Speed-adjustable DC motor
Stirrer: Full stainless steel clamp (durable and sturdy)
Stirring Speed: 1000 ±50 rpm
Timer Range: 99H 60M
Total Power: ≤2 kW
Power Supply: AC 220V ±10%, 50Hz
FAQ
Q1: What standards does this product (HKL-665 Rust-preventing Characteristics Tester) comply with? And what is the applicable scope of the instrument？
A: HKL-665 Rust-preventing Characteristics Tester conforms to the ASTM D665 Standard Test Method for Rust-Preventing Characteristics of Inhibited Mineral Oil in the Presence of Water. This is a test method to find out how well inhibited mineral oils, especially steam-turbine oils, can help prevent the rusting of iron parts in case water gets mixed with the oil. Besides being used in testing hydraulic oils and circulating oils, this method also allows testing heavier-than-water fluids.
Q2: Significance and use of HKL-665 Rust-preventing Characteristics Tester?
A: Water may become inadvertently mixed with the lubricant in several situations such as the gears of a steam turbine and rusting of ferrous parts may result. This test reveals the efficiency of the inhibited mineral oils in aiding the prevention of rusting of this kind. The test method in question is also suitable for the testing of hydraulic and circulating oils including heavier-than-water fluids. It is used for the specification of new oils as well as monitoring of in-service oils.
Q3: What is the minimum order quantity? How long is the delivery lead time?
A: The minimum order quantity is just one unit, and delivery will take around 20 days after receipt of your advance payment.
Q4: Do you provide product operation manuals or technical documentation?
A: Electronic versions can be provided upon request. We have different types of documents such as manuals, quick guides, application cases, and SOPs available in a digital format. You can either download these from our website or contact customer service to get them.
Q5: Can you provide some successful customer case studies?
A: Of course. We would love to tell you about the many ways we have been working with various research institutions, companies and universities. Besides proving the dependability of our products, this also gives you a chance to see how our instruments are being used in situations that may be very close to yours. We have set up a special CASE section on our main website. You can search for case introduction details by limiting the results to your industry or field. In case our public case library does not contain a case that exactly matches your requirements, you can reach out to us via the official website. We will then be able to supply you with anonymous or partially disclosed case references from that very industry, which are properly customized to your particular application area.
About us
Hong Kong Laboratory Technology Limited was founded in 2018. Since then, it has become well-established as a reliable supply chain collaborator in the field of scientific instruments. Over the past eight years of intensive work, we have assembled a powerful network comprising more than 50 top brands and serving over 500 clients. We not only facilitate Research and Development but also help with the transition to mass production. We are dedicated to carrying out our work according to the most stringent quality system management standards. Our main product lines meet major international standards such as ISO 9001, ASTM, and IP standards. They are also fully compliant with the ISO/IEC 17025 requirements for calibration and testing. In fact, our solutions are the first choice of research institutions, petrochemical and mining operations, healthcare centers, and environmental agencies globally.
Company Advantages
(1)Full-Chain Resource Integration Capability
(2)Professional Technical Service Team
(3)Rich Industry Practical Cases
(4)Reliable After-Sales Service
Service Guarantee
1. Online Training Services
If you want, our team members are ready to be online to guide you during installation and commissioning. We are eager to give your team complete operation training. Besides that, we give 24/7 online training services to end users all over the year to support them whenever they need it.
2. Professional After-Sales Service
We customize our maintenance services according to the unique features of your tools and machinery. Our strong commitment is to not only meet but exceed the world standards of quality and reliability. We always welcome your feedback as it is very important to us since it provides us with new ideas on how we can serve you better.
Logistics and Shipping
Worldwide Shipping: We have established a large global logistics network that ensures reliable and on-time delivery to the vast majority of locations. Our team has a deep knowledge of handling the unique export regulations and requirements of major international markets in Asia, the Americas, Europe, the Middle East, and Africa, meaning that your shipments will smoothly arrive at their destination.
Secure Packaging: Each piece of lab equipment is inspected individually before sending out and also packed very professionally using the high-density foam liners and strong cardboard boxes. The equipment inside the packaging is tied down very securely so that it can effectively resist vibrations, hits, and even damp situations during the travel. This way, the items will be in your hands in perfect condition.
International Certification
|
|
ISO 9001 Certification | ASTM Certificate |
