HKL-943 Apparatus for Oxidation Characteristics of Inhibited Mineral Oils
Overview
HKL-943 Apparatus for Oxidation Characteristics of Inhibited Mineral Oils conforms to ASTM D943 Standard Test Method for Oxidation Characteristics of Inhibited Mineral Oils. The oil sample is contacted with oxygen in the presence of water and an iron-copper catalyst at 95°C. The test continues until the measured acid number of the oil is 2.0 mg KOH/g or above. The number of test hours required for the oil to reach 2.0 mg KOH/g is the oxidation lifetime.
Features
This instrument adopts an imported digital temperature controller, ensuring accurate and high-precision temperature control with intuitive digital display.
The device features eight independent working units, allowing simultaneous testing of eight samples to save labor time. Each of the eight working units is equipped with individual flow rate adjustment for easy operation.
The metal bath is heated by electric heating tubes, enabling rapid temperature rise.
This water bath water bath is built with a pump circulation system and a cooling compressor, so it is possible to accurately adjust the temperature according to one’s needs.
Technical Parameters
Model: HKL-943
Heating Method: Electric heating tube
Temperature Control Method: Imported digital temperature controller
Temperature Control Range: Ambient temperature ~ 95°C
Pressure Display: Mechanical pressure gauge
Working Units: 8 test stations
Dimensions (L×W×H): 1200 × 730 × 530 (mm)
Total Power: 4 KW
Power Supply: AC 220V ±10%, 50Hz
Ambient Temperature: 5 ~ 40°C, Humidity: ≤85% RH
FAQ
Q1: What standards does this product (HKL-943 Apparatus for Oxidation Characteristics of Inhibited Mineral Oils) comply with? What is the applicable scope of the instrument?
A:HKL-943 Apparatus for Oxidation Characteristics of Inhibited Mineral Oils conforms to ASTM D943 Standard Test Method for Oxidation Characteristics of Inhibited Mineral Oils. This test method covers the evaluation of the oxidation stability of inhibited steam-turbine oils in the presence of oxygen, water, and copper and iron metals at an elevated temperature. This test method is limited to a maximum testing time of 10,000 hours. This test method is also used for testing other oils, such as hydraulic oils and circulating oils, having a specific gravity less than that of water and containing rust and oxidation inhibitors.
Q2: Significance and use of HKL-943 Apparatus for Oxidation Characteristics of Inhibited Mineral Oils?
A: This test method is widely used for specification purposes and is considered of value in estimating the oxidation stability of lubricants, especially those that are prone to water contamination. It should be recognized, however, that correlation between results of this method and the oxidation stability of a lubricant in field service may vary markedly with field service conditions and with various lubricants. The precision statement for this method was determined on steam turbine oils.
Q3: What is the minimum order quantity? How long is the delivery lead time?
A: The minimum order quantity is one unit, and delivery is approximately 20 days after advance payment.
Q4: How can I get a product quotation?
A: Please submit your requirements via the contact page on our official website or customer service email, and we will contact you within 24 hours with a detailed quotation.
Q5: Do you offer customized solutions?
A: Yes, we can provide customized instrument configurations and testing solutions based on the customer’s specific application need
