HKL-4185 AAS for Determination of toxic copper substances in workplace air
Overview
HKL-4185 AAS for Determination of toxic copper substances in workplace air conforms to the ASTM D4185 Standard Practice for Measurement of Metals in Workplace Atmospheres by Flame Atomic Absorption Spectrophotometry Copper. Workplace air samples are collected on membrane filters and treated with nitric acid to destroy the organic matrix and to dissolve the metals present. The analysis is subsequently made by flame atomic absorption spectrophotometry (AAS).
Samples and standards are aspirated into an appropriate AAS flame. A hollow cathode or electrodeless discharge lamp for the metal being determined provides a source of characteristic radiation energy for that particular metal. The absorption of this characteristic energy by the atoms of interest in the flame is related to the concentration of the metal in the aspirated sample.
Operating Conditions
Power Supply: 220V (+5% to -10%), 50/60 Hz; 5000VA.
Ambient Temperature: +15°C to +35°C.
Relative Humidity: 20% to 80%.
Technical Parameters
Optical System
1) Grating Ruling: ≥1800 lines/mm.
2) Effective Grating Ruled Area: ≥50x50 mm².
3) Wavelength Range: 190-900 nm.
4) Spectral Bandwidth: Five automatically adjustable settings (0.1, 0.2, 0.4, 1.0, 2.0 nm), with automatic wavelength slit width and energy calibration.
5) Wavelength Accuracy: ≤0.15 nm; Wavelength Repeatability: ±0.1 nm.
6) Baseline Drift: Static ≤±0.002 A/30 minutes, Dynamic ≤±0.005 A/30 minutes.
7) Instrument Spectral Resolution: Capable of resolving the manganese doublet at 279.5 nm and 279.8 nm, with a spectral bandpass of 0.2 nm/mm, and peak-to-valley energy between the two lines ≤30%.
8) Light Source: Six-lamp auto-switching turret with automatic alignment.
9) Lamp Current Setting: 0-30 mA, computer-controlled.
10) High-Performance Power Supply: Built-in high-performance dual-cathode lamp power supply.
Flame Atomizer
1) Characteristic Concentration (Cu): 0.015 μg/ml/1%
2) Detection Limit (Cu): 0.002 μg/ml
3) Precision: RSD ≤ 0.5%
4) Burner: Titanium burner, compatible with 50mm or 100mm burner.
5) Nebulizer: Pt-Ir capillary, Teflon nozzle, ceramic impact bead (suitable for hydrofluoric acid use).
6) Nebulization Chamber: Explosion-proof Corrosion-resistant Nebulization Chamber
7) Ignition Method: Microcomputer-controlled automatic ignition.
8) Gas Control: Fully automatic gas control system.
9) Adjustment System: Fully automatic PC-controlled flame/graphite furnace auto-switching with auto-optimization.
10) Multiple Safety Protection Features: Includes a built-in safety interlock system, a flashback-resistant gas circuit design, acetylene leak detection and alarm capabilities with automatic shut-off functionality, and automatic power-off protection in the event of system faults or anomalies.
Graphite Furnace Atomizer
1) Characteristic Mass (Cd): 0.5×10⁻¹² g
2) Detection Limit (Cd): 0.4×10⁻¹² g
3) Precision: RSD ≤ 3%
4) Heating Mode: Longitudinal heating
5) Safety Protections: Water flow rate, water temperature, gas pressure, poor graphite tube contact, overcurrent, and power alarm protections
6) Mode Switching: Integrated flame/graphite furnace automatic switching system, operated via a software-controlled electronic moving platform (requiring no manual disassembly).
7) Temperature Control Mode: Ambient temperature to approximately 3000°C; fully automated 20-step temperature control; up to 20 in-furnace pre-enrichment cycles; 4 heating ramp modes; features longitudinal optical monitoring of the inner wall temperature of the graphite tube.
Background Correction
1) Flame: Deuterium lamp + self-reversal background correction (capable of correcting up to 1A background)
2) Graphite Furnace: Deuterium lamp + self-reversal background correction (capable of correcting up to 1A background)
Data Processing
1) Measurement Modes: Flame mode, Hydride Generation mode, Graphite Furnace mode
2) Concentration Calculation Methods: Standard Curve Method (1st to 3rd, automatic regression), Standard Addition Method
3) Replicate Measurements: 1-99 times, calculation of mean value, standard deviation, and relative standard deviation
4) Result Output: Parameter printing, Data report printing, Graphical output printing, Export capability to WORD/EXCEL formats
5) User Interface: English operation interface, enabling automatic switching between flame and graphite furnace atomizers via software control.
6) Communication Interface: USB port for instrument-PC communication
Autosampler
1) Sample tray with 130 sample cups (2ml), 6 x 25ml cups for stock solutions, blanks, and matrix modifiers, 500ml wash bottle, and waste bottle.
2) Allows flexible designation of sample and reagent cup positions for random arrangement. Fully automated analysis begins after program setup.
3) Automated Calibration Curve Preparation: Automatically prepares standard solutions at a minimum of three concentration points via dilution from a single stock solution, and directly injects them into the graphite tube. (Functional Limitation: No in-line dilution capability.)
4) Minimum injection volume: 1μL (increments of 0.1μL), maximum injection volume: 100μL (analysis precision better than 1% for 10μL-100μL range).
5) Automatic long-term memory of syringe position with 50μm precision.
6) Graphite tube orifice fine adjustment range: ＞ ±5mm.
7) Fully automated standard addition method, supporting up to 20 standard samples.
8) Wash mode: Simultaneous internal and external washing with adjustable wash time and cycles.
9) Automatically initiates graphite furnace heating program after all solutions are injected.
FAQ
Q1: Which standard does this product (HKL-4185 AAS for Determination of toxic copper substances in workplace air) comply with?
A: HKL-4185 AAS for Determination of toxic copper substances in workplace air conforms to the ASTM D4185 Standard Practice for Measurement of Metals in Workplace Atmospheres by Flame Atomic Absorption Spectrophotometry Copper. Workplace air samples are collected on membrane filters and treated with nitric acid to destroy the organic matrix and to dissolve the metals present. The analysis is subsequently made by flame atomic absorption spectrophotometry (AAS).
Q2: What is the significance and use of HKL-4185 AAS for Determination of toxic copper substances in workplace air?
A:Assessing worker exposure to airborne toxic metals is critical for health protection. To evaluate the effectiveness of the control measures against standards, hygienists can perform air quality testing in the workplace. Flame Atomic Absorption Spectrometry (FAAS) is one of the official methods recognized by the government for the detection of metals in very small amounts which is also highly sensitive. This will provide the information that is essential for controlling work-related health issues such as skin and lung diseases.
Q3: Could you possibly share some compelling examples of customer success stories?
A: We would be really glad to share with you the time we have spent working with a lot of research institutions, companies and universities. This not only reflects the trustworthiness of our products, but at the same time could guide you in understanding how our instruments might be applicable to your situation. For that purpose only, a CASE section has been included by us on our official website. Within your industries or fields, you can simply select the cases you want to view by the filter function to see detailed case introductions. If you do not find a suitable sample in our public case library, you are always welcome to contact us through the official website, and we will provide you with anonymized or redacted case references from the same industry, area of application.
Q4: What is the minimum order quantity that you allow? Besides, how long does delivery generally take?
A: Minimum order quantity is really low - just one unit. After getting your payment in advance, you will most probably get your goods delivered in around 20 days.
Q5: Do you have relevant industry certifications?
A: We have got our enterprise certified with ISO9001 quality management system. Additionally, our products have been granted certificates such as CE and CPA (type approval for measuring instruments) which are the assurances of product quality and data reliability.
