HKL-2001M 6-Lamp Graphite Furnace Atomic Absorption Spectrophotometer
Overview
The elemental detection sensitivity level of this atomic absorption spectrometer is as follows: Cu at 1 µg/mL gives an absorbance of ≥ 0.3 (which in terms of sensitivity translates to ＜ 0.015 µg/mL for 1% absorbance). Thanks to their extensive versatility in a wide variety of analytical methods, owning just one piece from this series will allow you to set up a fully equipped and state-of-the-art laboratory, thereby making it extremely appropriate for analytical research and development work in a broad range of establishments.
Technical Parameters
1. Operating conditions
1.1 Power Supply: 220V (+5% to -10%), 50/60 Hz; 5000VA.
1.2 Ambient Temperature: +15°C ~ +35°C.
1.3 Humidity Range: 20～80%
2. Technical specifications
2.1 Optical System
2.1.1 Grating Ruling: 1800 lines/mm.
2.1.2 Wavelength Range: 190–900 nm.
2.1.3 Spectral Bandwidth: Five-step automatic adjustment (0.1, 0.2, 0.4, 1.0, 2.0 nm).
2.1.4 Wavelength Accuracy: ≤ 0.15 nm; Wavelength Repeatability: ± 0.05 nm.
2.1.5 Baseline Drift: Static: ≤0.002 A/30 min, Dynamic: ≤0.004 A/30 min
2.1.6 Light Source: Automatic turret with 6 lamps, Auto-collimation
2.1.7 High-Performance Power Supply: Dual-Cathode power supply for lamps.
2.2 Graphite Furnace Atomizer
2.2.1 Characteristic Mass (Cd): 0.3×10⁻¹² g
2.2.2 Detection Limit (Cd): 0.2×10⁻¹² g
2.2.3 Precision: RSD ≤ 2%
2.2.4 Heating Mode: Longitudinal heating
2.2.5 Safety Protections: Water flow rate, water temperature, gas pressure, poor graphite tube contact, overcurrent, and power alarm protections
2.2.6 Switching Mode: Integrated flame/graphite furnace auto-switching system with electronic mobile platform controlled by software (no manual disassembly required)
2.2.7 Temperature Control Method: Room temperature to ~3000°C, fully automated 20-step temperature control, up to 20 in-furnace preconcentration cycles, 4 heating ramp modes, Longitudinal optical monitoring of inner wall temperature of graphite tube.
2.3 Background Correction
2.3.1 Graphite Furnace: Deuterium lamp + self-reversal background correction (capable of correcting up to 1A background)
2.4 Data Processing
2.4.1 Measurement Modes: Graphite Furnace mode
2.4.2 Concentration Calculation Methods: Standard Curve Method (1st to 3rd, automatic regression), Standard Addition Method
2.4.3 Replicate Measurements: 1-99 times, calculation of mean value, standard deviation, and relative standard deviation
2.4.4 Result Output: Parameter printing, Data report printing, Graphical output printing, Export capability to WORD/EXCEL formats
2.4.5 User Interface: English operation interface, Intuitive software control, achieve automatic switching between flame atomizer and graphite furnace atomizer.
2.4.6 Communication Interface: USB port for instrument-PC communication
Trace Elements Measurable
Elements detectable by graphite furnace atomic absorption spectrometry with low sample volume and high sensitivity (PPb-level):
Ag, Al, As, Au, Ba, Be, Bi, Ca, Cd, Ce, Co, Cs, Cu, Dy, Er, Eu, Fe, Ga, Ho, In, K, La, Li, Mg, Mn, Mo, Na, Ni, Pt, Os, Pb, Pd, Pr, Hf, Rb, Rh, Ru, Sb, Sc, Se, Sm, Sn, Zr, Te, Ti, V, Zn, Si, etc.
