HKL-4925 Apparatus for Fluidity at low temperature
Overview
HKL-4925 Apparatus for Fluidity at low temperature conforms to the ISO 4925 Road vehicles — Specification of nonpetroleum-based brake fluids for hydraulic systems. The apparatus is applicable for determining the fluidity and appearance changes of brake fluid at low temperatures, used to evaluate the low-temperature stability of the brake fluid.
Features
The instrument has been built according to the standard specifications to ensure that it fully satisfies the testing requirements laid down.
This instrument adopts imported compressor refrigeration technology, which means that the instrument doesn’t need any circulating cooling water. It uses fan air cooling and upon power connection, it can achieve rapid refrigeration.
The instrument is fitted with a smart digital-display PID temperature controller for accurate control. Besides, the very accurate PT100 sensor greatly enhances resolution, anti-interference ability, and accurate temperature control.
The instrument is equipped with a copper tube cold chamber of φ280×200mm size, which not only provides a large cold storage capacity but also facilitates easy sample handling to the users.
The instrument controller uses a timer to regulate the Sample Preparation Time, displaying a range of 99H59M on an intuitive screen while ensuring precise and accurate timekeeping.
The heating system consists of electric heating rods and allows accurately controlling the temperature of the cooling bath.
Technical Parameters
Model: HKL-4925
Cold Chamber Dimensions: φ280×200mm
Refrigeration Method: Imported compressor refrigeration
Heating Method: Electric heating rod
Temperature Control Method: Imported digital display PID temperature controller
Refrigeration Range: 0 to -60℃
Temperature Control Accuracy: ±1℃
Timer Range: 99H59M
Total Power: ≤2KW
Rated Voltage: 220V±10%, 50Hz
Overall Dimensions: 380mm×600mm×1330mm
Ambient Temperature: Room temperature
Relative Humidity: ≤85%RH
FAQ
Q1: What standards does this product (HKL-4925 Apparatus for Fluidity at low temperature) comply with?
A: HKL-4925 Apparatus for Fluidity at low temperature conforms to the ISO 4925 Road vehicles — Specification of nonpetroleum-based brake fluids for hydraulic systems. The apparatus can be used to measure the changes in fluidity and visual appearance of brake fluid at low temperatures, it is employed to assess the brake fluid’s stability at low temperatures.
Q2: Do you provide samples?
A: If you want small consumables or accessories, we can give you samples after a negotiation (sample fee and shipping costs will be charged). As for instrument-type products, because of their high price, the best way as a reference is either the case studies of similar users or a demonstration visit can be arranged.
Q3: How do I track my order?
A: When the shipment is sent out, we will give you the tracking number / bill of lading number and a tracking link. By using the courier’s or logistics company’s website, or by contacting our customer service, you will be able to track your shipment in real-time.
Q4: Do you provide product operation manuals or technical documentation?
A: Yes, we offer electronic versions of product manuals, quick operation guides, application cases, and standard operating procedures (SOPs). These can be accessed by logging into the download center on our official website or by contacting customer service to request them.
Q5: Do you provide online training services?
A: Should you suffer from any difficulties, you can avail of our online installation and commissioning services and also operation training that is comprehensive. Besides this, we give 24/7 online training support for end users throughout the year.
