HKL-1881 Apparatus for Foaming Tendency of Engine Coolants
Overview
HKL-1881 Apparatus for Foaming Tendency of Engine Coolants conforms to ASTM D1881 Standard Test Method for Foaming Tendencies of Engine Coolants in Glassware. A solution of coolant and ASTM type Ⅱ water is blown with air at a constant rate for 5 min, while maintained at a constant temperature of 88 ± 1°C(190 ± 2℉) by means of a suitable temperature bath. The volume of foam, and the time for such foam to break, are measured.
Features
This instrument adopts a left-right structure design with a large-capacity cylindrical glass bath, reducing temperature deviation inside the bath. It features rapid heating, high heat, and excellent temperature stability.
This instrument comes with an air filter and flow meter, and it has a compact design that makes it very easy to operate and observe.
With this device, one can set the temperature point anywhere from 0-88℃ and the instrument will control it automatically.
The temperature control system of this instrument uses a digital display temperature controller which has fast response to sensors, high resolution, etc. It is also strong anti-interference and high precision controller of temperature.
The instrument’s constant temperature bath features three measuring cylinders so it is possible to test 3 samples at the same time or carry out parallel tests.
The instrument consists of a main pneumatic control valve and three independent flow meters, which allow adjustment of the air flow very accurately.
The flow meters in the instrument make it possible to accurately control the flow of air, and the user can set the flow rate of the gas to whatever is desired. PT100 temperature sensors are used for temperature measurement. These sensors are very sensitive and can measure a wide range of temperatures.
Technical Parameters
Applicable Standard: ASTM D1881
Heating Method: Electric Heating Tube Heating
Temperature Control Method: Digital Display PID Temperature Control
Stirring Method: Motorized Stirring
Bath Capacity: Φ300 × 450 mm
Test Temperature: 88 ± 0.1°C
Sample Bath Holes: 3 Holes
Gas Diffuser Permeability: 3000–6000 ml/min
Power Supply: 220V ± 10%, 50Hz, 2KW
FAQ
Q1: What standards does this product (HKL-1881 Apparatus for Foaming Tendency of Engine Coolants) comply with?
A: HKL-1881 Apparatus for Foaming Tendency of Engine Coolants conforms to ASTM D1881 Standard Test Method for Foaming Tendencies of Engine Coolants in Glassware. A simple glassware technique is described by this test method for assessing the foaming proclivity of engine coolants in a laboratory environment where the conditions of aeration and temperature are controlled.
Q2: What is the significance of HKL-1881 Apparatus for Foaming Tendency of Engine Coolants?
A: The testing procedure mainly provides a way to separate coolants that foaming might be a big problem from the ones that are okay to be tested further for their service performance.
Q3: What is the minimum order quantity? How long is the delivery lead time?
A: Minimum ordering quantity is one unit, and the lead time for delivery is about 20 days after payment in advance.
Q4: Do you provide product operation manuals or technical documentation?
A: We provide electronic formats of product manuals, quick operation guides, application cases, and standard operating procedures (SOPs). You may access them by logging into the download center on our website or by asking customer service to send you the files.
Q5: Do you provide online training services?
A: Should you require help at any point, we will extend to you installation and commissioning services online, thorough operational training, besides 24/7 all year round online training support for end user.
