HKL-1122 Apparatus for Density of Engine Coolants
Overview
HKL-1122 Apparatus for Density of Engine Coolants conforms to ASTM D1122 Standard Test Method for Density or Relative Density of Engine Coolant Concentrates and Engine Coolants By The Hydrometer. This test method covers the determination of the relative density of engine coolant concentrates and engine coolants. The values stated in SI units are to be regarded as standard.
Features
Imported digital temperature control is featured by the instrument for both measurement and regulation. It guarantees automatic, precise, and high-accuracy temperature management. Moreover, the set points are adjustable over the entire effective heating range.
The instrument adopts an electric heating tube as heating source, the temperature is controlled by the digital display temperature controller. The instrument featuress a Pt100 sensor for temperature measurement, which provides high sensitivity, excellent resolution, and strong anti-interference ability. The pocket design allows to accurately control and measure temperature, digital display ensures precise and intuitive readings.
A motor-driven stirring system is responsible for doing away with the thermal stratification in the bath effectively. Besides ensuring a uniform temperature distribution, it also significantly reduces the workload of the operator.
This device is strictly designed according to standards, with a compact, precision-engineered and highly functional design.
The instrument is designed for installation and maintenance without the need for tools. All internal connections are made via industrial-grade plug-in terminals to ensure quick servicing.
This instrument featuress immersion refrigeration technology, achieving high-efficiency heat extraction.
Technical Parameters
Model: HKL-1122
Heating Method: Electric heating tube
Heater Power: 2.5 kW
Temperature Control point: 20°C
Bath Dimensions: φ300 × 300 mm
Temperature Control Method: Imported PID controller
Temperature Control Accuracy: ±0.1°C
Stirring Motor: 14W, 1450 rpm
Operating Environment: Ambient Temperature: 0~45°C, Relative Humidity: ≤80% RH
Power Supply: 220V ±10%, 50Hz
Total Power Consumption: ＜3 kW
FAQ
Q1: What standards does this product (HKL-1122 Apparatus for Density of Engine Coolants) comply with?
A: HKL-1122 Apparatus for Density of Engine Coolants conforms to ASTM D1122 Standard Test Method for Density or Relative Density of Engine Coolant Concentrates and Engine Coolants By The Hydrometer. This test method provides an outline for measuring the relative density of engine coolant concentrates and engine coolants.
Q2: What is the significance of HKL-1122 Apparatus for Density of Engine Coolants?
A: Relative density of an engine coolant gives us the ability to estimate percent glycol, freezing point, and boiling point of the coolant, assuming we know the type of glycol used. Relative density of an engine coolant concentrate, on the other hand, may be utilized for production control testing purposes.
Q3: What is the minimum order quantity? How long is the delivery lead time?
A: The minimum order quantity is just a single unit, and delivery time is about 20 days after receiving the advance payment.
Q4: Do you provide product operation manuals or technical documentation?
A: Yes. We make available e-versions of user manuals, quick start guides, application examples, and standard operating procedures (SOPs) of our products. One way to get these resources is through our official website, or else simply reach out to customer service.
Q5: Do you provide online training services?
A: When the situation demands, we can offer you online installation and testing services. Besides, we will train you how to operate the equipment effectively. In addition to that, we provide 24-hour online training support to end users all year round.
