HKL-1384 Apparatus for Corrosion of Engine Coolants
Overview
HKL-1384 Apparatus for Corrosion of Engine Coolants conforms to ASTM D1384 Standard Test Method for Corrosion Test for Engine Coolants in Glassware. This test method covers a simple beaker-type procedure for evaluating the effects of engine coolants on metal specimens under controlled laboratory conditions.
Features
The Heating Bath of the instrument is Metal bath.
It can be used for automatic temperature control at any set point between ambient temperature and 88 °C.
The temperature control system is based on a Japanese Fuji digital PID temperature controller with a very quick sensor response, high resolution, good anti-interference capability, and high accuracy in temperature measurement and control.
Flow meters control the airflow and allow adjustment as per the requirements. PT100 sensors provide both sensitive detection and a wide measuring range.
The unit is designed to work with three test wells, which allows simultaneous sample testing for comparing the results. Every heating bath has been outfitted with a gas nozzle which is connected through silicone tubes to create a thorough gas supply system.
The instrument is equipped with a master pressure gauge valve and three separate flow meters to make air flow control very easy.
An air pump supplies the gas, and gas nozzles can be used to connect the equipment to the external gas sources if necessary.
Technical Parameters
Model: HKL-1384
Heating Bath: Metal bath
Bath Dimensions: Φ100 × 170mm
Number of Baths: 3
Temperature Control Method: Imported digital PID temperature controller
Temperature Control Range: Ambient temperature ~ 88°C ± 0.1°C
Air Flow Meter Range: 25 ~ 250 ml/min
Air Pump Supply Rate: 100 ± 10 ml/min
Tall-form, spoutless Beaker Capacity (Dimensions): 1000ml (Φ98 × 200mm)
Gas-dispersion Tube: Sintered glass dispersion head, Φ15 × 30mm
Total Power: 2.8 KW
Power Supply: AC 220V ± 10%, 50Hz
FAQ
Q1: What standards does this product (HKL-1384 Apparatus for Corrosion of Engine Coolants) comply with?
A: HKL-1384 Apparatus for Corrosion of Engine Coolants conforms to ASTM D1384 Standard Test Method for Corrosion Test for Engine Coolants in Glassware. The intent of this test procedure is to provide a simple beaker-style method for assessing the impact of engine coolants on metal specimens in a laboratory environment where conditions are closely controlled.
Q2: What is the significance of HKL-1384 Apparatus for Corrosion of Engine Coolants?
A: This product basically identifies those coolants that from the viewpoint of corrosion are very harmful and those that are okay for further evaluation. Nevertheless, the outcome of this testing method cannot by itself be considered conclusive evidence of excellent corrosion prevention. An engine coolant mixture’s real performance value can be found only through more complete laboratory, dynamometer, and real-world testing.
Q3: How can I get a product quotation?
A: You can leave your requirements to us on the Contact Us page of our official website or customer service email. We shall get back to you with a detailed quotation within 24 hours.
Q4: Do you provide product operation manuals or technical documentation?
A: Yes. We provide electronic versions of product manuals, quick operation guides, application cases, and standard operating procedures (SOPs). The easiest way to get them is to log into the download center on our official website. Alternatively, you may call customer service and they will be glad to send you the documents you request.
Q5: How do I track my order?
A: When the shipment is sent out, we will give you the tracking number / bill of lading number and a tracking link. By using the courier’s or logistics company’s website, or by contacting our customer service, you will be able to track your shipment in real-time.
