HKL-9050 FTIR Spectrometer for Glass Transmittance Measurement
Overview
HKL-9050 FTIR Spectrometer for Glass Transmittance Measurement conforms to ISO 9050 the Glass in building — Determination of light transmittance, solar direct transmittance, total solar energy transmittance, ultraviolet transmittance and related glazing factors. This International Standard specifies methods of determining light and energy transmittance of solar radiation for glazing in buildings. These characteristic data can serve as a basis for light, heating and ventilation calculations of rooms and can permit comparison between different types of glazing. The scope of this International Standard covers both traditional glazing units and the solar-control glazing units which absorb or reflect the solar rays that are used as glazed apertures. Appropriate expressions for single, double and triple glazing are given. Also, the overall calculation methods for multiple components units are set up.
Features
Highly stable optical system: The optical bench uses integrated design with monolithic mold forming, where essential components are placed in alignment at a single time without need of adjustment. It greatly increases the stability of the instrument and totally eliminates maintenance problems of the old style optical parts.
Advanced Electronic Architecture: The system is equipped with a top-end 24-bit A/D converter that works at a 500 kHz sampling rate, along with a high-quality imported infrared detector of high sensitivity. Through this combination, the system can constantly record spectral data very accurately and reliably. Thanks to the newly added USB 2.0 communication interface that has brought about a great improvement in data transfer speed, it is now possible to finish the whole sample analysis in a matter of seconds.
Smart Humidity Control System: A real-time humidity sensing hermetically sealed interferometer has been combined with a spectrometer, thereby almost eliminating the need for the operator to maintain it. A simple visual sign changes its color to indicate when it is time to replace the desiccant—it is the top risk that FTIR analysis is trying to eliminate. Without having to open the instrument casing, one can even change the desiccant.
Unitary Corner Mirror Technology: Introducing gold-plated mirrors into both moving and stationary optical paths inspires this combination to fetch highest luminous flux and reflectance from the design. The instrument constructed with no adhesive does not revert to changes in ambient temperature and so has improved inherent stability.
Premium components sourced globally: To make sure they are of the highest quality, all key parts – including the light source, detector, beam splitter, and die – are sourced from the best manufacturers in Europe and America.
Technical Parameters
Spectral Range: 7800–350 cm-1
Resolution: better than1.0 cm-1
Signal-to-Noise Ratio: 30000:1 (Peak-to-Peak value, 4 cm-1 resolution, 1-minute background and sample scan, Test wavenumber: 2100 cm-1), RMS value: 150000:1
Detector: This system features a high-sensitivity infrared detector of international origin. It is engineered for high-precision testing, ensuring excellent result repeatability. Its robust design requires minimal maintenance and guarantees long-lasting performance.
Beamsplitter: Precision multilayer-coated potassium bromide (KBr), imported.
Scanning Speed: Microcomputer-controlled with selectable scanning speeds, continuously adjustable, automatic spectrum comparison.
Light Source: Long-life, high-intensity air-cooled system (imported)
Wavenumber Accuracy: 0.01 cm-1
Software Workstation: The instrument comes with a dedicated workstation that grants access to approximately 200,000 standard infrared spectral libraries.
Noise Level: ＜4.3 × 10-5 A
Power Supply: AC 220V, 50Hz
Data Transmission Interface: High-speed USB 2.0
Operating system: win7/win10
Weight: 14kg
FAQ
Q1: What standards does HKL-9050 FTIR Spectrometer for Glass Transmittance Measurement comply with?
A: HKL-9050 FTIR Spectrometer for Glass Transmittance Measurement conforms to ISO 9050 the Glass in building — Determination of light transmittance, solar direct transmittance, total solar energy transmittance, ultraviolet transmittance and related glazing factors. The scope of this International Standard covers both the traditional glazing units as well as the solar-control glazing units that absorb or reflect the solar rays and are used as glazed apertures.
Q2: What is the applicable scope of HKL-9050 FTIR Spectrometer for Glass Transmittance Measurement?
A: This International Standard lays down methods for assessing the light and energy transmittance of solar radiation through building glazing. The characteristic data thus obtained may serve as the basis for performing room lighting, heating and ventilation calculations and for the purpose of comparison of different types of glazing. This International Standard may be used for ordinary glazing units as well as for solar-control glazing absorbing or reflecting, as glazed apertures. Appropriate formulas for single, double and triple glazing are included. Besides, it provides most common calculation methods for units having larger number of components.
Q3:Do you provide product user manuals or technical documentation?
A: Yes, Among other ways, we communicate with our customers through electronic transmission of product manuals, quick operation guides, application cases, and standard operating procedures (SOPs). You can get these either by logging to the download center at our official website or by getting in touch with customer service to ask for them.
Q4: What application fields do your instruments cover?
A: Scientific research centers, petrochemical and mining industries, medical institutions, and environmental protection agencies are widely using our instruments. This exceptional quality has gained product recognition in the market and customer loyalty.
Q5: Instruments are precision equipment. How is their safety ensured during transportation?
A: Our professional instrument packaging team uses customized shock-absorbing foam boxes and reinforced wooden crates. We also work with logistics providers specializing in precision instrument transportation so that the goods will be delivered to you safely and without any damage.
