HKL-1193 Ultra-Pure Water System
Overview
The HKL-1193 Ultra-Pure Water System conforms to the ASTM D1193 Standard Specification for Reagent Water and ASTM D5127 Standard Guide for Ultra-Pure Water Used in the Electronics and Semiconductor Industries. Such an instrument may be used to satisfy chemical analysis and physical test methods’ water requirements while also meeting the water quality specifications for electronics and semiconductor industry manufacturing matters.
Features
7-inch colored touchscreen, control system of the menu is animated.
Startup self-check, alarms for water shortage and leakage, and automatic shut-off upon dripping are some of the help features.
More advanced touch-contact water dispensing help when operation is not only flexible but also very convenient.
Monitor the quality and temperature of raw water, RO water, and UP water at real-time.
Consumable maintenance management function, showing the consumable life left and automatically remind of replacement.
Password protect system settings to prevent unauthorized changes.
RO membranes will be flushed automatically and thoroughly to effectively prevent scaling and extend the useful life of membranes.
A water quality alarm feature that will go off automatically if the readings are lower than the preset limits.
Recirculation done automatically to ensure water quality remains stable continually.
Setting the system time (year/month/day/hour/minute), flushing time, timed shutdown (0-24h), and standby/sleep mode (0-60 minutes).
Service period configuration options for pre-treatment, RO membrane, UV lamp, and ultrapure water pack.
Regular setup has two-stage reverse osmosis, a UV disinfection module, and a last filter.
The housing, made of mold-injected plastic, is a one-piece, visually attractive design.
Running status signal lights on circulation, water making, flushing, tank full, and water shortage are built-in.
Password protection of all system settings with two-level password system (factory and user).
Pre-treatment work for the water source is done to equip it with particulates, residual chlorine, organic matter, and odors.
30L standard liquid level tank with water level and volume display, and pressure tank compatible.
TOC (total organic carbon) online monitoring is a feature to quantitate organic carbon in water.
USB port as a standard connection to allow logged data and print quality water reports to fulfill genuine and vital application requirements.
Technical Parameters
Feed Water Source: Total Dissolved Solids (TDS) ≤ 200 ppm, Water Pressure 0.10~0.40 MPa, Water Temperature 5~45°C
Pre-treatment Unit: Three-stage multi-functional composite type
Water Production Capacity: 10/20 (L/H)
Product Water Flow Rate: 1.5~1.8 (L/min) (when the tank is full)
UP (Ultrapure) Water Quality: Resistivity 18.2 MΩ·cm @ 25°C (online monitoring)
Conductivity: 0.055 μS/cm
Microparticles ≤ 1 count/ml, Microorganisms ≤ 1 cfu/ml
Heavy Metal Ions ＜ 0.1 ppb, TOC ≤ 5 ppb, Pyrogens ＜ 0.001 EU/ml
Ribonuclease (RNases) ＜ 0.5 pg/ml
Deoxyribonuclease (DNases) ＜ 5 pg/ml
RO (Reverse Osmosis) Product Water Quality: Double-stage 1-5 μS/cm (online monitoring)
Main Unit Dimensions: 603 × 390 × 530 (mm)
Main Unit Weight: 35 kg
Power Supply: AC 220 V / 50 Hz (Power: 55 W)
Tank Configuration: 30 L liquid-level tank
Application Scenarios: Labs involved in Life Sciences, Chemical Analysis, Materials Nanotechnology, Environmental and Food Testing as well as Medicine Clinical Research, Pharmaceuticals Quality Control, Scientific Research and Educational Institutions.
FAQ
Q1: What fields is the ultrapure water system suitable for?
A: The main application fields of this product are laboratory analysis and life science research requiring ultra-pure water, such as High-Performance Liquid Chromatography (HPLC), Mass Spectrometry (MS), Ion Chromatography (IC), Atomic Absorption Spectroscopy (AAS), Molecular Biology experiments (PCR), cell culture, reagent preparation, and glassware rinsing.
Q2: Does the system have any requirements for the feed water quality?
A: To be on the safe side in terms of the quality of produced water and the durability of consumables, one should use Reverse Osmosis (RO) water, distilled water, deionized water, or drinking water as the feed. In case tap water is used directly, one should consider installing an internal or external RO pre-treatment system (including a PP sediment filter, activated carbon filter, and softening resin) as the system will automatically adjust operating parameters according to feed water quality and will alert you when pre-filters need replacement.
Q3: Is it easy to operate? Does it require dedicated personnel for maintenance?
A: It is really very simple to use. It has a large color touchscreen and a high resolution so you can easily see at one glance what the water quality is, the water temperature, the consumable status, any alarm notifications, etc. These kinds of systems are usually capable of measuring the quantity of water dispensed and have automatic circulation functions. Daily cleaning and maintenance consists mainly of changing consumables periodically according to the system’s prompts without the need for a professional technician.
Q4: What is the minimum order quantity? How long is the delivery lead time?
A: The minimum order quantity is just one unit and delivery is approximately 20 days after advance payment.
Q5: What international shipping options do you support?
A: We provide several flexible global shipping methods for your convenience: (1) International Express: We team up with top courier firms worldwide, e.g. DHL, FedEx, UPS, and TNT, zipping delivery for small packages and treasure items. (2) Air Freight: Best for medium volumes, it gives you a fair balance between price and speed. (3) Sea freight is a good option for big orders. It can offer you a whole container or a part container. The journey takes about 20-40 days depending on your port of arrival. (4) Rail freight is focused on the advantage of China-Europe Railway Express, available for customers in the Eurasian continent like Central Asia, Russia, Europe, and also other places. It is both a stable and efficient service.
