HKL-FFH-300 Hydrogen Generator
Features
Operation is easy: To start the gas production, simply flip the power switch and a constant output pressure will be maintained.
The flow rate can be seen on an LED digital display which is very clear and simple to read.
The purifier consists of PC polycarbonate tubes that offer great resistance against pressure, chemical changes, and impacts, as well as long-lasting capability due to the inherent strength of the material.
The daily maintenance is just daily replenishing of distilled water, allowing the machine to be used continuously.
Working with integrated design (including reservoir, hydrogen production through electrolysis, and oxygen discharge) at low cell temperature and with longer cell life.
It comes with a liquid anti-backflow device, which guarantees that no reverse flow in the instrument.
Technical Parameters
Flow Rate: 0–300 ml/min
Hydrogen Purity: 99.999%
Output Pressure: 0–0.6 Mpa (Factory default setting: 0.3 Mpa ± 0.1 Mpa)
Water Requirement: Purified water, distilled water, or deionized water
Power Supply: AC 220V ± 10%
Max. Power Consumption: 150W
Dimensions (L×W×H)/ Weight: 425 mm × 210 mm × 365 mm/ 10 kg
FAQ
Q1: What is the main purpose of a hydrogen generator?
A: Hydrogen generators produce very pure hydrogen for different uses. They are connected to Gas chromatographs (GC) to supply fuel gas for detectors like Flame Ionization Detectors (FID) or Flame Photometric Detectors (FPD). They deliver a number of different reaction gases on demand as well. These units do away with the need for high-pressure hydrogen cylinders, and instead provide a safer, more convenient, and continuous source of hydrogen for laboratories.
Q2: What purity level does the hydrogen you produce have?
A: This equipment is based on state-of-the-art Proton Exchange Membrane (PEM) pure water electrolysis technology. It generates hydrogen of up to 99.999% purity (dry and free of hydrocarbons) totally satisfying the high-purity specifications for gas chromatography analysis.
Q3: Can the generator’s flow rate keep up with the requirements of my gas chromatograph?
A: Different models are available from us with flow rates between 300 ml/min and 1000 ml/min. These can be single or multiple gas chromatograph setups running at the same time. You can decide the right model according to your number of instruments and hydrogen demand. In case of any queries, please do not hesitate to contact our technical team.
Q4: How long does it take to produce stable hydrogen after startup?
A: After startup, instrument normally achieves set pressure and purity within 5-10 mins, and then quickly goes to stable working condition with NO long waiting times.
About us
Hong Kong Laboratory Technology Limited specializes in supply chain integration and full-chain technical services for laboratory instruments. With years of industryexpertise, our company operates under a stringent quality management system, complying with multiple international standards including ISO 9001, ASTM, and IP requirements. The core products not only comply with the ISO/IEC 17025 instrument calibration and testing standards, but are also widely used in research institutions, petrochemical and mining industries, medical institutions,and environmental protection departments. This high-standard quality has earned broad market and customer trust.
Company Advantages
Service Guarantee
1. Online Training Services
If assistance is needed, we will provide online installation and commissioning services, as well as comprehensive operation training for you. Meanwhile, we also offer 24/7 online training support for end users throughout the year.
2. Professional After-Sales Service
According to the type of instrument, we can provide specialized maintenance services. Our goal is to become the highest-quality and most reliable instrument supplier in the market. We welcome your valuable opinions and suggestions to help us continuously improve our service quality.
Logistics and Shipping
Worldwide Shipping: We have extensive experience in shipping goods to Asia, Europe, the Middle East, and other regions.
Secure Packaging: Laboratory instruments are carefully packed to ensure they are properly secured and protected during transit.
International Certification
|
|
ISO 9001 Certification | ASTM Certificate |
