HKL-UPTpro Water System (Color Touch Screen)
Overview
The HKL-UPTpro Ultra-Pure Water System conforms to the ASTM D1193 Standard Specification for Reagent Water and ASTM D5127 Standard Guide for Ultra-Pure Water Used in the Electronics and Semiconductor Industries. This instrument fits the water requirement criteria of chemical analysis and physical testing methods. Besides, it also meets the water quality specifications associated with electronics and semiconductor industry manufacturing.
Features
The entire housing is made with one-time mold injection molding, resulting in a beautiful and slim looking body.
5.1-inch color touch screen with an intuitive and lively interface control system.
Includes features such as startup self-check, water level alarm, and auto-shutdown when the container is full.
Featuring a sophisticated touch-activated water dispensing mechanism for easy and comfortable use.
The quality and temperature of RO (Reverse Osmosis) and UP (Ultra-Pure) water are monitored continuously.
The consumable life management feature shows the amount of life left and gives you automatic replacement alerts.
Password protected system settings so no unauthorized data changes can be made.
Automatic flushing of the RO membrane to prevent scaling and prolong membrane life.
Water quality alarms will be set off automatically when levels are below the set thresholds.
Imported Terminal Filter: 0.2μm PES filtration membrane is capable of microbial retention and hence it can effectively remove particles and bacteria.
Automatic quality-controlled circulation ensures stable water quality all the time.
The system can be set for time (year/month/day/hour/minute), flushing duration, timed shutdown (0–24h) and standby sleep mode (0–60 minutes).
Users can set their preferences for how long pre-filters, RO membrane, UV lamp, and ultra-pure water cartridge last.
Additional features that can be added: dual-stage reverses osmosis, UV sterilization module, and UF ultrafiltration membrane.
Operation status signal are provided for modes such as circulation, water production, flushing, full tank, and low water.
Two-level password protection (factory and user) allows for system configuration security.
The pre-treatment system can eliminate particulate matter, residual chlorine, organic compounds, and odors in the feed water.
The main unit uses ABS material, with water-electricity separation to prevent corrosion, resist moisture, and improve safety.
Ultrapure Cartridge: The full downward-flow purification is used in this cartridge to avoid resin stratification and the column efficiency is thus well maintained.
Electrodes: Permit in situ, very accurate determination of UP and RO water quality.
Dual-Wavelength UV Lamp (185/254): Original imported lamp- great for lowering TOC levels while also sterilizing and preventing bacterial growth.
Relevant Image Examples
|
|
|
|
|
|
|
|
|
|
|
|
Imported Terminal Filter | Ultrapure Cartridge | Electrodes | Dual-Wavelength UV Lamp |
Technical parameters
Model:HKL- UPTpro
Water Source: Total Dissolved Solids (TDS) ≤ 200ppm, Water Pressure 0.10–0.40MPa, Water Temperature 5–45°C, Pretreatment Unit: Three-stage multi-functional composite type
Water Production Capacity: 10/20 (L/H)
Output Flow Rate: 1.5–1.8 L/min (when the water tank is full)
UP (Ultrapure) Water Quality:
1)Resistivity: 18.2MΩ·cm @ 25°C (online monitoring)
2)Microparticles: ≤1 particle/ml, Microorganisms: ≤1cfu/ml
3)Heavy Metal Ions: ≤0.1 ppb, TOC: ≤10 ppb
4)Endotoxins: ≤0.001 EU/ml, Ribonuclease (RNases): ＜0.5 pg/ml
5)Deoxyribonuclease (DNases): ＜5 pg/ml
RO (Reverse Osmosis) Water Quality Conductivity Range:
1)Single-stage: 1–10 μ S/cm (online monitoring)
2)Double-stage: 1–5 μ S/cm (online monitoring)
UF Ultrafiltration Membrane (Optional)
UV Ultraviolet Lamp (Optional)
Double-Stage Reverse Osmosis (Optional)
Final Filter (Optional)
Main Unit Dimensions: 630 × 390 × 525 (mm)
Main Unit Weight: 35 kg
Power Supply: AC 220V / 50Hz (Power: 55W)
Water Tank Configuration: 3.2G Pressure Tank
FAQ
Q1: What is the minimum order quantity? How long is the delivery lead time?
A: We require only one unit as the minimum order quantity, and the delivery time is about 20 days from when advance payment is received.
Q2: What fields is the ultrapure water system suitable for?
A: This product is mainly used for laboratory analysis and life science research which require ultra-pure water, such as High-Performance Liquid Chromatography (HPLC), Mass Spectrometry (MS), Ion Chromatography (IC), Atomic Absorption Spectroscopy (AAS), Molecular Biology experiments (PCR), cell culture, reagent preparation, and the final rinsing of glassware.
Q3: How can I obtain a product quotation?
A: Kindly submit your requirements through the contact page of our official website or customer service email, we promise to get back to you within 24 hours with a detailed quotation.
Q4: Could you share a few customer success stories with us?
A: It would be our pleasure to use our extensive experience collaborating with university, business, and research institution communities. Such experience not only confirms the reliability of our products but also gives us some perspective on their performance in settings similar to yours. Our website includes a dedicated CASE section where you are able to view cases curated by your area of expertise or industry only. If the public portfolio does not have an example that suits you, please contact us through our website. We shall then be able to provide you with some sector related cases that have had confidential aspects either removed or anonymized.
Q5: Is it easy to operate? Does it require dedicated personnel for maintenance?
A: The operation is quite straightforward. Equipped with a high-resolution color touchscreen, the system shows all details (water quality, water temperature, consumable status, alarm messages) at a glance. Besides that, the system can perform quantitative water dispensing and automatic circulation functions. Most of the time, daily maintenance means just replacing the consumables according to the system’s prompts, and a professional technician is not needed.
