HKL1265 LP-Gas Injector Cylinder of laboratory Solutions
Overview
The HKL1265 LP-Gas Injector Cylinder of Lab Solutions conforms to the ASTM D1265 Standard Practice for Sampling Liquefied Petroleum (LP) Gases, Manual Method and ISO 4257 Liquefied petroleum gases — Method of sampling. The intended use of this product is for sampling, transferring, and storing toxic and hazardous substances and gases including liquefied petroleum gas (LPG), liquefied natural gas (LNG), hydrogen sulfide (H2S), waters containing sulfur, hydrocarbon compounds, and gases such as nitrogen (N2), oxygen (O2), and carbon dioxide (CO2).
Features
Made from seamless tubing and shaped by spinning process.
There are no welding faults. The 316L Stainless Steel has a very high level of resistance to corrosion and can also withstand high temperatures.
After pickling and passivation of the inner surface, the wall thickness remains uniform and quite easy to clean.
Obtain the national production-license and Sampling-Cylinder patent certificates.
It is equipped with a safety explosion-proof pressure relief device.
Select from a variety of over ten different types of accessories.
Double-ended Cylinder Body having female quarter inch threaded ends NPT.
Rupture disc work on 870psi or 3600psi.
Teflon/PTFE Coating can be customized
Technical Parameters
Working Pressure: 3000psi and (5000psi)
Design Pressure: 4500psi and (7500psi)
Operation Temperature: -60ºC~+80ºC
Material: 316L
Suitable Medium: Non-corrosive liquid, gas and gas-liquid mixtures for 316L stainless steel under the specified range of temperature and pressure.
Capacity: 50 ml, 100ml, 150 ml, 200ml, 250ml, 300ml, 500ml, 1000ml, 2000ml, 2500ml, 4000ml, 5000ml, 10000ml
Applications
LPG stainless steel gas cylinder has a wide range of application, mainly serving petrochemical, pharmaceutical, teaching and scientific research, food inspection and other industries.
It can be used in current conventional devices, such as storage tanks, tank cars, tower equipment, production lines, etc.
-Liquefied Gas Injector (LGI)-Laboratory Solutions
-Sampling and Analysis of Liquefied Gases using the BRT Liquefied Gas Injector
-Setting the ASTM and EN Standards for Oily Residues Analysis in LPG by GC Petro Online
-Laboratory Solutions Liquefied Gas Injector (ASTM D7756-13/ EN 16423) is used in Gas Chromatography laboratories
-The Liquefied Gas Injector: analyzing LPG and Butadiene contaminants
-Liquefied Gas Injector - Joint Analytical Systems
Accessories (PTFE Coating)
| Outage tubes | Lab shelf |
| Metal soft tube/Flexible hose | Sample injection needle |
| Pressure gage | Quick coupling |
| Filter | Pipe fittings |
| Aluminum sampling bag | Pressure reducer |
| Low temperature needle valve | Cylinder special needle valve |
| clip nut | — |
FAQ
Q1: What is the main purpose of an LPG sampling cylinder?
A1: The main aim of this innovation is to quickly and precisely gather and keep samples of LPG or other liquefied gases under pressure from pipelines, storage tanks, or vehicles, etc., in a way that meets the current standards (e.g., ASTM D1265). These samples are then sent to laboratories to determine what they contain, their purity, or compliance with the requirements. This equipment is indispensable for quality control and also for the turnover in the petrochemical, gas supply, and quality inspection industries.
Q2: What kind of international shipping support can you provide?
A2: We offer flexible international shipping that can adjust exactly to your needs. If you have small, precious articles, we can arrange the fastest delivery through DHL, FedEx, UPS, or TNT. Medium shipments that are not urgent, can be delivered by air freight at prices that compete with the market. Orders of bulk goods can be delivered by sea freight in both FCL and LCL modes (transit time: 20-40 days depending on the destination). For the most stable and efficient service through Eurasia, rail freight can be sent through the China-Europe Railway Express.
Q3: What special precautions should be taken when using this cylinder for sampling?
A3: The core considerations are safety and sample representativeness:
1). Safety First: Operators have to be trained on the dangers of high-pressure gases and liquefied gases (flammable and explosive). They should wear personal protective equipment, such as safety goggles and gloves, while sampling, and the work should be carried out in a /well-ventilated, ignition-free area/. 2). Compliance Check: Make sure that the cylinder is still in the period of validity of the inspection before use, the valve does not leak and there is no serious corrosion or damage to the exterior of the cylinder 3). Secure Connection and Purging: For connecting a sampling port, use exclusive adapters. Besides that, before taking a sample, intensively purge the cylinder as well as the main lines in order to get rid of air and residues so that the sample remains uncontaminated. 4). Do Not Fill Too Much: Always tightly control the volume of filling based on the standards. A cylinder is not allowed to be completely filled with liquid.
